Atlas Outdoors: TetonX
{{ galleryProps.activeIndex + 1 }}/14
Configuration
Specs
- Dry Weight (lbs): 3500
- GAWR (lbs): 5000
- GVWR (lbs): 5000
- Tongue Weight - Dry (lbs): 350
- Payload (lbs): 1500
- Overall Length - Travel (ft): 16.8
- Overall Length - Opened (ft): 16.8
- Body Length (ft): 11
- Exterior Height - Travel (in): 90
- Exterior Height - Opened/Camping (in):
- Exterior Height - Storage (in):
- Interior Height - Opened (in): 80
- Exterior Height Notes: 90.25 with top down and suspension lowered
- Interior Height - Travel (in): 59
- Exterior Width (in): 90
- Exterior Width Notes:
- Interior Length (in):
- Interior Width (in):
Company
- Manufacturer: Atlas Outdoors
- Manufacturer Headquarters: USA - St George, UT
- Foreign or Domestic (USA) Manufacturer: Domestic Manufacturer
- Country of Manufacturing - Origin: USA
- Country of Manufacturing - Completion: USA
- Manufacturer Notes:
- Manufacturing Since (Year): 2023
- Stock Availability: Pre-Order: 3-6 months
- Class: Hybrid Caravan
- Brand: Atlas Outdoors
- Model: TetonX
- Floorplan:
- Warranty:
- Model Year: 2025
- Trim Level:
Sleeping Configuration
- Sleeping inside the Cabin: 5
- Total Sleeping Capacity - Including Annex or RTT: 7
- Sleeping Configuration Notes: Main bed can be queen or king. Upper bunk can be single 24" or double 48". Optional front shelf as bunk.
- Main Bed Mattress Type: 4" Memory Foam
- Main Bed Mattress Size: Queen
- Main Bed Mattress Dimensions (in): 76 x 61
- Bed Notes: Main bed can be set up as optional King with upgrade
- Lower Bunk Size (in): 24" x 76" (Front shelf bunk)
- Top Bunk Size (in): 2x 24" x 70"
- Other Bed Size (in): Optional Rear 2 person tent
Manufacturing Materials
- Zero Wood Construction: No - Contains Some Wood
- Use of Wood: Interior or Kitchen Cabinetry
- Frame Design & Material: 6" Boxed Steel
- Frame Treatment: Powercoated
- Wall Construction:
- Wall Insulation:
- R-Value:
- Floor Base Material: Composite
- Pop Up / Hybrid Material: Polyvinyl Chloride (PVC)
- Canvas: No
- Exterior Color / Wrap Options: Multiple color combinations
Suspension & Hitch
- Hitch: Articulating - Cruisemaster D035
- Single or Tandem Axle: Single
- Suspension: Trailing Arm - Proprietary
- Airbag Leveling: Standard
- Parking Handbrake: Yes - Upgrade
Off Road Capabilities
- Departure Angle (degrees):
- Tongue Height (in):
- Ground Clearance to Frame (in):
- Wheelbase Length - hitch to axle (in):
- Undercarriage Protection:
- Standard Tire & Rim Size: 265/70 R17
- Max Tire Size (in): 35"
- Standard Tires Brand: BF Goodrich - All Terrain KO3
- Standard Wheels Brand: Fuel Alloy
- Standard Bolt Pattern: 6 x 139.7mm
- Positive Pressure Dust Supression: Not Available
- Custom Bolt Pattern Available: No
- Recovery Points: Rear - 2" Receiver
- Water Crossing Height (in):
- Track Width:
Off Grid Capabilities
- Undercarriage & Water Tank Notes: Water tank sits above floor, no exposed wiring or water plumbing below floor.
- Fresh Water Tank Max Capacity (gal): 30
- Grey Tank Available: Not Available
- Black Tank Available: Not Available
- Grey & Black Tank Notes:
- Propane Standard: 11lb x1
- Propane Max: 20lb x2
- Water Filtration: None
- Fresh Water Tank Configuration (if multiple): 1x 30 gal, sits above floor in cabin under dinette bench
- Batteries - Standard: 330Ah - LiFePO4
- Batteries - Max Capacity: 660Ah - LiFePO4
Power Management
- Shore Charging: Victron - Multiplus 3000VA Inverter/Charger
- Solar Charging: Included - Victron - 30amp MPPT
- Mounted Solar Panels: None - Manufacturer Upgrade Available
- Mounted Solar Panels (max upgrade): 490W
- Portable Solar Panel Port: Yes - SAE
- Inverter: Victron - Multiplus 3000VA
- DC to DC Charging: Option - Victron - 30Amp
- Power Monitoring via Bluetooth / Phone App: Yes - Standard
- Fresh Water Tank Monitor: Yes - non Bluetooth
- Grey & Black Tank Monitor: None
- USB / 12v Receptacles: 6
- Starlink: Starlink Gen 2 or 3 Port - RJ45 - Optional/Dealer
- 120v Receptacles: 3
Kitchen
- Indoor / Outdoor Kitchen: Outdoor Kitchen with Interior Sink
- Outdoor Cooktop: Propane - CampChef Portable
- Indoor Cooktop: Not Available
- Microwave: Not Available
- 12v Refrigerator/Freezer: Option - Dometic CFX 75L DZ
- 12v Cooler Max Dimensions:
- Other Kitchen Notes:
- Outdoor Sink Plumbing:
Ammenities
- Total Storage Capacity (cu in):
- Furnace: Included - Truma Vario Heat - Propane
- Hot Water: Included - Truma AquaGo - Propane
- Air Conditioning: Option - 12v Rooftop
- 4 Season / Winter Camping Protection: Interior Protected Water Tank & Plumbing
- Stand Up Inside: Yes
- Interior Dinette / Seating: Yes - 4 People
- Interior Dinette Size:
- Stealth Camping Capable: Yes
Bathroom
- Interior Ensuite with Shower / Wet Bath: No
- Built-in Toilet Type: None
- Accomodates Interior Portable Toilet: Yes
- Outdoor Shower: Yes – Optional Double Enclosure
Accessory & Gear Options
- Rear / Front 2" Receiver: Yes - Standard Rear
- Bike Rack Option: Yes - Rear Receiver
- Moto Mount Capable: No
- ATV or Toyhauler Option: No
- Roof Rack for Kayaks or Large Gear: Yes - Optional
- Awnings: Included - OVS 270, Option - Bush Company 180 XT, Option - Bush Company 270 XT Max
- Annex Room: Option - Awning Walls (not full enclosure)
- Roof Rack Size:
- Roof Rack Rated Weight:
- Accessory & Gear Notes:
